Dunlop MXR CAE Boost/Overdrive Effects Pedal

The Boost/Overdrive combines the popular Boost/Line Driver circuit with a punchy, dynamic overdrive circuit. The Boost/Overdrive offers the combination of a simple dynamic overdrive and an independent clean boost circuit—all in one compact pedal. The overdrive section is truly "classic", adding warmth, sustain and punch, without coloring your sound. It can go from a bluesy, slightly overdriven sound to full-metal crunch with a twist of the gain knob. The MC402 also cleans up nicely when you roll back your guitar volume, making it extremely touch sensitive and responsive to picking dynamics, without becoming thin sounding. The boost circuit alone is a bonus, as it is the exact same circuit CAE has used for years to solve a wide variety of signal conditioning problems in major guitar systems. The MC402's high quality components provide quiet operation and trouble-free interaction with other pedals on your board. In keeping with the CAE tradition, the design is simple and straight forward, with a minimum of controls—only what is necessary to do the job. This pedal can be powered by a 9-volt battery, a Dunlop ECB003 9-volt adapter, or the DC Brick™, Iso-Brick™, and Mini Iso-Brick™ power supplies (not included).

Specifications

Input Impedance: 1k ohms

Output Impedance:
   Boost ON <150 ohms
   Overdrive ON/Boost OFF <15k ohms

Boost Gain: 20 dB

Signal to Noise Ratio: >87 dB

Bypass: True Hardwire

Controls: Boost/Overdrive Pedal switches, BOOST knob, OUTPUT knob, TONE knob, GAIN knob

Connectors: INPUT jack (1/4"), OUTPUT jack (1/4")

Current Draw: <5.5 mA

Option (sold separately): AC adaptor
